Automatic Syringe Assembly Machine for Disposable Syringe Production

Syringe Assembly Process Overview

• The syringe assembly process is a critical stage in disposable syringe manufacturing, where individual molded components are automatically assembled into finished syringes with consistent quality and high efficiency. A typical automatic syringe assembly process includes the following steps:

• 1. Component Feeding and Orientation

• Syringe barrels, plungers, and other components are automatically fed into the assembly system through vibration bowls or conveyors. Precise orientation ensures that each component enters the assembly process in the correct position.

• 2. Automatic Insertion and Assembly

• The plunger is accurately inserted into the syringe barrel using controlled mechanical or pneumatic systems. Assembly parameters are precisely set to maintain dimensional consistency and smooth movement of the plunger inside the barrel.

• 3. Lubrication and Siliconization

• Medical-grade silicone oil is applied to the inner surface of the syringe barrel during assembly. This step ensures smooth plunger movement and stable injection performance while meeting medical usage requirements.

• 4. Needle Mounting (Optional)

• For syringes requiring needle assembly, the needle hub is automatically mounted and secured to the syringe barrel. The assembly process is designed to ensure reliable connection and alignment in compliance with medical standards.

• 5. Inspection and Output

• Assembled syringes are inspected for assembly accuracy, appearance, and functionality. Qualified products are automatically discharged for downstream processes such as packaging or sterilization.

• This automated syringe assembly process improves production efficiency, reduces manual handling, and ensures consistent product quality, making it suitable for modern disposable syringe manufacturing lines.




Haijiang Syringe Assembly Machine installed with LCD display to display the feeding speed, and can adjust the assembly speed separately, with electronic counting. High efficiency, low power consumption, easy maintenance, stable operation, low noise, suitable for the GMP workshop.

Syringe Assembly Machine is used for assembling medical syringe automatically. It can produce all kinds of syringes, including luer slip type, luer lock type, dental syringe,insulin syringe etc.

The speed of assembly machine has increased from 220  to 350 per minute (from 1ml to 10ml). Increased accuracy of each part of the equipment.

Applications of Syringe Assembly Machines

• Disposable syringe manufacturing lines

• Medical syringe production facilities

• Automatic syringe assembly for ISO / GMP plants

Safety cover is adopted and stop automatically when the cover is opened.

This device can assemble syringes of various specifications, including mid-head, screw-on, and off-head. Automatic feeding and assembly of various parts of the product.

The equipment will not pollute products and clean area, and can be produced continuously for 24 hours.
